The typical accuracy of a 3 jaw chuck, measured as total runout, often ranges around 0.002" to 0.010", depending on condition, setup, and quality. Good maintenance and techniques can reduce this closer to 0.002" or better. However, 3 jaw chucks generally do not reach the extremely tight tolerances of 4 jaw independent chucks, which can have runout as low as 0.0001" to 0.001" when carefully adjusted.
Key points on 3 jaw chuck accuracy:
A worn or improperly maintained 3 jaw chuck may show runout around 0.0035" or more, but cleaning and regrinding the jaws can improve this to about 0.0025" total runout (meaning about 0.00125" off center).
Professional and hobby machinists report typical runout for 3 jaw chucks in the range of 0.002" to 0.0085" total indicator movement, depending on chuck quality and setup.
Some highly careful setups, including selecting the correct mounting orientation and tightening sequence, can routinely achieve runout as low as 0.0003" on smaller diameter stock.
The 3 jaw chuck is self-centering, making it faster and easier to use for quick setups but limiting its adjustment accuracy compared to 4 jaw chucks, which allow independent jaw adjustment for minimal runout.
Accuracy depends heavily on maintenance, cleanliness, jaw wear, and proper mounting/ tightening technique. Marking and consistently tightening keyholes on the chuck can help achieve best accuracy.
For very precision work (below about 0.001" runout), a 4 jaw chuck or additional setups with dial indicators is recommended.
In summary, a well-maintained and properly used 3 jaw chuck can reliably hold concentricity within around 0.002" total runout for general work. Fine tolerance work typically requires switching to a 4 jaw chuck due to its adjustability and better achievable accuracy. The 3 jaw remains popular for its speed and ease of use even if it has somewhat lower precision limits
